SCADA systems (Supervisory Control and Data Acquisition): evolutions and market 2022

A look at the definition of SCADA, the role of the SCADA system, the evolutions of Supervisory Control and Data Acquisition in the age of cloud and IoT and SCADA system market forecasts until 2022.

The global SCADA market is expected to grow at a CAGR of 5.01% to reach US$15.373 billion by 2022, from US$12.041 billion in 2017

In our article on Industry 4.0 we briefly touched upon SCADA, short for Supervisory Control and Data Acquisition. SCADA is part of the operational technology landscape but sits close to the IT dimension of the so-called automation pyramid which we tackled in our article on the manufacturing sector and manufacturing technology evolutions.

As written in our overview of operational technologies, the scope of OT is mainly to be seen in the monitoring of physical processes and physical devices in a context of control, automation, diagnosis and operational processes.

SCADA and the SCADA system play a key role here, more specifically in industrial processes and automation. And just as is the case in operational technologies, Industrial IoT and related technologies such as cloud computing (and soon cognitive computing, edge computing and perhaps even blockchain, if we look at the future of the MES and ERP systems with intelligent ERP) take center stage in the evolutions of SCADA systems whereby some even see the end of SCADA in a distant future (most see IIoT and SCADA as complementary).

SCADA Supervisory Control and Data Acquisition - SCADA purpose definition components and market forecasts 2022

There is a Supervisory Control and Data Acquisition system in an industrial process near you

Supervisory Control and Data Acquisition software monitors, processes and analyzes industrial processes whereby it sits on the production level of Industry 4.0, in-between the process control level of PLCs (programmable logic controllers) where the regulation of machines and systems occurs (control of manufacturing processes) and the operations level (where in manufacturing we, for instance find the Manufacturing Execution System).

The key attribute of a SCADA system is its ability to perform a supervisory operation over a variety of other proprietary devices

However, SCADA isn’t just a matter of manufacturing where it serves as the industrial process control system to monitor, control and supervise the product line.

SCADA systems traditionally are seen as consisting of various levels beside the software dimension. A Supervisory Control and Data Acquisition system then comprises field instrumentation (instruments to monitor and control automation processes), the mentioned programmable logic controllers and RTUs (Remote Terminal Units), the data communication layer and telemetry (nowadays better known as remote monitoring) and, finally, the SCADA host or SCADA supervisory computer system with the SCADA software or HMI software.

Programmable Logic Controllers (PLCs) and Remote Telemetry Units (RTUs) used to be distinctly different devices but over time they are now almost the same. This has been a convergence of technology as manufacturers of these devices expanded their capabilities to meet market demands (Schneider Electric)

When people talk about Supervisory Control and Data Acquisition they often mean the industrial process control software which then essentially collects real-time data from and communicates with the field controllers that run the actual industrial process such as the PLCs and RTUs.

Just as is the case with operational technologies in general, SCADA is used in all possible areas where there are industrial processes, ranging from manufacturing, travel and transport, oil and gas, healthcare, water treatment, water distribution and electrical power distribution to facility processes in smart buildings, HVAC (heating, ventilation, and air conditioning), critical power buildings (airports, hospitals,…) and building management processes overall.

As Carl Gould, co-director of software engineering at Inductive Automation explains in the video below this brief SCADA introduction, Supervisory Control and Data Acquisition systems, which are effectively used for controlling, processing and monitoring industrial processes, are also used in wastewater systems, petrochemical systems, food and beverage, utilities and far more. In other words: the list is long.

The Supervisory Control and Data Acquisition market in flux: evolutions, drivers and SCADA market forecasts 2022

As is the case with all operational technologies, building automation technologies and manufacturing technologies, the SCADA market, which goes back to the days of minicomputers, has been evolving throughout the years, hand in hand with the various evolutions in information technologies.

SCADA is now a critical solution for connecting the distributed assets of a plant in order to generate actionable intelligence - a SCADA system is a critical first step in establishing interoperability - quote Alan Cone Siemens Industry

In general, four generations of Supervisory Control and Data Acquisition systems are defined. It probably won’t come as a surprise that in the current fourth, generation, IoT and Industrial IoT as said play a major role.

Despite being around since quite some time the SCADA market shows growth in this evolving context with drivers such as the ever more important need for high uptime in manufacturing, smart supply chains, maintenance and asset management and Industry 4.0 goals overall, the need for higher operational efficiency, the ease of controlling and monitoring of industrial processes and superior quality & quantity.

These are some of the main drivers of the SCADA market as found in research that offers forecasts with regards to the SCADA market until 2022.

According to the announcement of the report (November 16, 2017) the worldwide SCADA market is poised to grow at a compound annual growth rate or CAGR of 5.01 percent until 2022. It might not be the kind of double-digit or even triple-digit CAGR that we see in some other industrial markets but with a forecasted total SCADA market revenue of US$15.373 billion by 2022 (revenue in 2017 totalled US$12.041 billion) the SCADA market is not exactly the smallest.

By way of comparison and as IoT (and cloud) play such a role in fourth generation SCADA systems: total revenue of the IoT platform market in 2018 (which is about to explode in 2019-2020 but already is hot now) will be approximately $3.0 billion.

Communication is the absolute most essential link for a SCADA system to operate properly; however, how well the system manages communication from HMI to RTUs and PLCs fundamentally determines how successful a SCADA system can be (Donald Krambeck, All About Circuits)

The mentioned SCADA market research announcement also contains a SCADA definition: “SCADA (Supervisory Control and Data Acquisition) is used to gather and analyze real-time data and comprises of remote terminal units, programmable logic controller, telemetry, and Human Machine interface”.

On top of the previously mentioned SCADA market drivers also the high investments in infrastructure for various sectors and high potential from the renewable energy sector are poised to add to the growth of the industry. The latter again shows how energy-efficient technologies in buildings and energy efficiency in general rank high on the agenda of industries in the broader scope of ecology and technologies and sustainability.

Supervisory Control and Data Acquisition security challenges and SCADA security solutions

Throughout the many evolutions of SCADA systems a pretty constant challenge has existed on the level of security. In fact, we should again add that this isn’t just the case for SCADA but for many operation technologies.

An important part of most SCADA implementations is alarm handling. The system monitors whether certain alarm conditions are satisfied, to determine when an alarm event has occurred

Especially when Supervisory Control and Data Acquisition systems entered the second (distributed, with local area networks), third (networked, with often geographically spread process control networks, leveraging more than one local area network) and now fourth generation (cloud, IoT and interfacing with data modelling and what we could call digital twins), that security aspect became even more important, especially the cybersecurity aspect.

However, SCADA security was already a security in the early days as in the end when you talk about power systems, oil and gas and so forth by definition you speak about mission-critical, yet decentralized facilities, including things like gas pipelines and energy grids. Moreover, SCADA systems by definition are often leveraged for the control of geographically dispersed field controllers that can span huge areas.

These kinds of environments were connected by SCADA systems which were designed by engineers to be solid and robust and not from a security perspective as we understand it in IT and in today’s hyper-connected context. Once more we need to add that this is an issue with regards to OT and the integration of IT and OT as well.

The four functional levels of a distributed control system or DCS in the third generation of SCADA in manufacturing control operations - Wikipedia - Daniele Pugliesi
The four functional levels of a distributed control system or DCS in the third generation of SCADA in manufacturing control operations – Wikipedia – Daniele PugliesiCC BY-SA 3.0

Despite evolutions with regards to SCADA security, the previously mentioned report states that even at the end of 2017 the cybersecurity threat remains the major restraining factor.

Smart devices throughout the plant become part of the SCADA network facilitating the data flow (Alan Cone, WinCC Marketing Manager, Siemens Industry)

One of the major challenges with regards to the overall security of SCADA systems, the human-machine interface (HMI) seems to be the weakest link as reported by Trend Micro in its SCADA/HMI security report. And of course then we are talking about SCADA/HMI software.



Below is a SlideShare presentation, uploaded on November 16, 2017, which dives much deeper in SCADA security, among others offering security guidelines.



Embedded security layers in control, safety, and SCADA systems enable Industry to benefit from mobile and cloud computing. More

What is SCADA? Supervisory Control and Data Acquisition definitions and components in summary – the visual way

Earlier we mentioned the video from Inductive Automation. It’s embedded below since as per usual videos and illustrations as you can see some below are the best definitions and explainers (aside from of course being actively busy with Supervisory Control and Data Acquisition).

This is how Wikipedia defines SCADA: “Supervisory control and data acquisition is a control system architecture that uses computers, networked data communications and graphical user interfaces for high-level process supervisory management, but uses other peripheral devices such as programmable logic controllers and discrete PID controllers to interface to the process plant or machinery. The operator interfaces which enable monitoring and the issuing of process commands, such as controller set point changes, are handled through the SCADA supervisory computer system. However, the real-time control logic or controller calculations are performed by networked modules which connect to the field sensors and actuators.”

And this is how Carl Gould illustrates that SCADA definition in the video below:

A Supervisory Control and Data Acquisition system:

  • Is used for controlling, monitoring and analyzing an industrial process;
  • Starts by communicating in real-time with the controllers in the field that are running the actual process, typically PLCs (Programmable Logic Controller) or RPUs (Remote Terminal Unit);
  • Gathers the data from these field controllers and brings them in the Supervisory Control and Data Acquisition system where they are then presented to the operators that are running the process, using a graphical interface;
  • Allows the operators to see in real time what the process is doing;
  • Enables operators to react to alarms, control the process, change setting and so forth;
  • Often includes some sort of a historian product so that the real-time process information can be tracked over the long term;
  • Can be used to create charts, run reports and that way enable operators of industrial processes not just to see what happens now but also in the past and in the future with predictive capabilities.

And there you have it: data (including metadata from PLC register paths and alarm analytics as this introduction article on SCADA systems on All About Circuits by Donald Krambeck reminds us) in the scope of industrial processes with an increasing importance of IoT and IT.

The five components of the SCADA system are mentioned in the same article and in the earlier cited press release with forecasts for the Supervisory Control and Data Acquisition market:

  1. Remote Terminal Units (RTUs)
  2. Programmable Logic Controllers (PLCs)
  3. SCADA communication systems/infrastructures
  4. The mentioned Human Machine Interface (HMI)
  5. The supervisory system

The image below from the article gives an idea of a basic Supervisory Control and Data Acquisition system set up.

Basic SCADA system diagram with different components such as the HMI SCADA server PLC sensors and RTU - courtesy and source All About Circuits
Basic SCADA system diagram with different components such as the HMI, SCADA server, PLCs, sensors and RTUs – courtesy and source All About Circuits

Also the people of Inductive Automation have a very good overview of what SCADA is with loads of information on the basics, usage, roots and evolutions of SCADA and Supervisory Control and Data Acquisition systems as they are.

However, do remember that IoT is playing an increasing role which, among others, is translated in the support of typical IoT devices, systems and protocols on top of database, OT protocols and plenty of others (the systems connect with database systems, they don’t “have” one).

B-Scada, which also has an IoT platform (the Status Device Cloud IoT Platform) and a smart city solution (the CitiWorx Sensing Platform) for example offers machine-level HMI software and a Supervisory Control and Data Acquisition system software solution offering data connectivity ‘for thousands of devices and systems”, such as OPC UA, OPC DA, SNMP, MQTT, REST, Bar Code, GPS, Domoticz, Empress, SQL and ODBC data sources, Excel workbooks, Allen Bradley, BACnet, Modbus and Siemens S7 devices, as well as Monnit, Libelium, Advantech Wzzard, and B-Scada sensors. Custom data sources can also be supported.

Below is another depiction of a basic SCADA Architecture as featured on the mentioned overview page from the people at Inductive Automation.

Basic SCADA architecture diagram showing the various components and interactions in a Supervisory Control and Data Acquisition environment - courtesy and source Inductive Automation
Basic SCADA architecture diagram showing the various components and interactions in a Supervisory Control and Data Acquisition environment – courtesy and source Inductive Automation

SCADA – the next steps and a deeper dive in the shifting role of Supervisory Control and Data Acquisition systems in the digital factory

In order to offer you a deeper dive into the various developments and evolutions in SCADA Systems, below is a white paper by one of the market players, Schneider Electric (on top of the previously mentioned ones others include Siemens, Rockwell Automation, General Electric, ABB, Yokogawa Electric, Omron, Honeywell and Emerson Electric).

It goes back to 2012 and by definition does not include the very latest developments as the market keeps evolving with, among others, smart devices increasingly becoming part of the SCADA network, facilitating the data flow, to quote Alan Cone, WinCC Marketing Manager, Siemens Industry, from a November 2017 article / press release on the need and ways to reexamine the role of SCADA systems in digital manufacturing operations, but it sure does contain deeper insights into the evolutions and far more.

SCADA Systems by Marcio Rocha on Scribd



To conclude a word in the scope of the digital transformation of manufacturing, IIoT, cyber-physical systems, the Internet of Things in manufacturing, Industrial Internet, Industry 4.0, industrial automation and all the other terms we use nowaday.

In the previously mentioned article on the need to reexamine the role of SCADA in digital manufacturing operations and the digital and smart factory overall, Alan Cone from Siemens sees five areas where modern SCADA systems like the company’s WinCC add value to a functioniing digitalized plant.

The SCADA contribution to the digital manufacturing data flow, according to him, plays on the levels of:

For now we close with the words of Cone who states that as a manufacturer works to modernize a plant with digitalization being a competitive manufacturing advantage, adding a SCADA system  is a critical first step in establishing interoperability.

SCADA systems now have the available power of cloud computing; these systems can report close to real-time accuracy and use cloud environments to implement more complex algorithms. These algorithms otherwise would not be implementable on traditional PLCs or RTUs (Donald Krambeck, All About Circuits)

And of course the advantages of interoperability help in enabling a more competitive manufacturing environment with major benefits being that 1) plant and IT systems begin to communicate (including a more direct exchange that can take place as plant-level functions connect with management platforms such as the MES, ERP and soon intelligent ERP), 2) decisions to optimize plant processes can happen quicker (and soon in a more autonomous way as AI is making its way in the future factory and also the intelligent ERP), 3) energy savings, 4) improved production uptime and 5) synergistic improvement.
